Early Products

Throughout our history, Collins Aerospace, Inc. has produced a multitude of products. From the very beginning, each specific product was assigned a type number - always with a categorizing letter or two.
We are presently logging some of the early products into a database. When completed, it will provide our readers insite into our product-line legacy.

There are 221 so far - it will take a while to capture them all!! In time we will be changing the way the information is displayed and maybe a search tool or two.
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
2A Antenna Tuner Rack-mounted antenna tuner. - - - view.jpg
2C Antenna Tuner
p/o 30FXB		 Rack-mounted Antenna Tuner. - - - -
2D Antenna Tuner Multi-band antenna tuner unit. - - - view.jpg
3A RF Power Amplifer
p/o 150W & 150BW		 When used in connection with the 10A Crystal Control Unit, will deliver 150 watts on the 160, 80, and 40 meter bands; 120 watts on 20 meters. - - view.pdf -
4A HF Transmitter Crystal Controlled, CW transmitter with built-in power supply for the 160 & 80 meter (28 watts), 40 meter (25 watts), and 20 meter (13.2 watts) amateur radio bands. view - - -
5A Microphone Condenser-type Microphone. - - - -
6A Speech Amplifier Rack-mounted speech preamplifier, fixed gain settings. - - - view.jpg
6J Isolation Amplifier Rack-mounted broadcast audio isolation amplifier designed to match 500-600 ohm input channels to the studio’s mixer console circuitry. view - - -
7C Speech Amplifier Rack-mounted or Portable speech amplifier designed primarily for a crystal microphone. When portable, used for field-to-studio link - over leased telephone lines. -February 13, 1935 - - - view.jpg
7M Speech Amplifier
p/o 202A, 600A		 Speech amplifier featuring 83db gain at 7 watts output. Inputs for sound-cell or diaphragm crystal microphones including VU meter to monitor audio modulation. - - - -
7R Monitor Amplifier Rack-mounted broadcast audio amplifier for speech monitoring circuits. view - - -
7X Speech Amplifier Portable Speech amplifier - - - view.jpg
8B Beat Frequency Oscillator Portable audio test equipment. - - - view.jpg
9C Modulator Unit
p/o 30W or 40B		 Class B phone modulation unit for the 30W and the 40B Transmitters. - - - -
9K Modulator Unit
p/o 150C		 - - - - -
10A Crystal Control Unit
p/o 150W & 150BW		 Crystal-controlled exciter, or PA, for the 160, 80, 40, and 20 meter amateur radio bands. - - view.pdf -
10M RF Unit
p/o 30FXC or 150C		 The 10M 175 watt RF unit is used as an exciter for transmitters, like a 30FXC, operating at frequencies from 1.5 to 30 mHz. - view.jpg - -
10P RF Unit
p/o 30FXC or 150C		 The 10P 175 watt RF unit is used as an exciter for transmitters, like a 30FXC, operating at frequencies from 1.5 to 10 mHz. - view.jpg - -
10X RF Unit
p/o 30FXC or 150C		 The 10M 100 watt RF unit is used as an exciter for transmitters, like a 30FXC, operating at frequencies from 10 to 30 mHz. - view.jpg - -
12B Speech Rack Rack-mounted speech equipment. Four 6A Pre-amplifiers, one four-channel Mixer Panel, and two Patch Panels. -September 15, 1934 view - - view.jpg
12F Speech Input Assembly Complete system of rack-mounted speech processing components - for broadcast studio operation. view - - -
12H Speech Console Broadcast studio operator’s speech mixing console. view view.jpg - -
12X Portable Microphone Amp. Battery-operated, three-channel microphone amplifier for remote-to-studio audio circuit. view - - -
12Y Remote Amplifier Single channel microphone amplifier and matching coupler for remote-to-studio link phone lines. view view.jpg - -
12Z Remote Audio Amplifier Battery-operated, three-channel amplifier for remote-to-studio audio circuit. view view.jpg - -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
15A HF Transmitter/Receiver
p/o 18D		 Three-band unit, part of an 18D ship-set, manufactured for the Colombian Air Force in the late 30’s. - - - view.jpg
16A HF Transmitter/Receiver
p/o 18C		 Three-band unit, part of an 18C ship-set, manufactured for the Colombian Air Force in the late 30’s. - - - view.jpg
16E HF Transmitter 2-20 mc, 150 watt A1, A2 & A3, 10 channel, Autotune® transmitter. - view.jpg - -
16EA HF Transmitter 2.5-20 mc, 150 watt, 300-500 kc 90 watt A1, A2 & A3, 10 channel, Autotune® transmitter. - view.jpg - -
16F HF Transmitter 2-16 mc, 300 watt A1, 500 watt A2 & A3, 10 channel, Autotune® transmitter. view view.jpg - -
16FA HF Transmitter 2-16 mc, 500 watt A1, 300 watt A2 & A3, 150 watt 300-500 kc, 10 channel, Autotune® transmitter. - view.jpg - -
16F-14 HF Transmitter 2-20 mc, 250 watt phone, 400 watt CW, 10 channel, Autotune® transmitter. - - view.pdf -
17A HF Receiver
p/o 18B		 Four-band receiver unit, part of an 18B ship-set, manufactured for the Colombian Air Force in the late 30’s. - - - view.jpg
17A HF Transmitter
p/o 18B		 Four-band transmitter unit, part of an 18B ship-set, manufactured for the Colombian Air Force in the late 30’s. - - - view.jpg
17D Airborne Transmitter 100 watt, 10 channel Autotune® airborne and ground use transmitter. - view.jpg - -
17F-5 Multi-frequency Transmitter 100 watts, 2,500-20,000 kc, 10-channel Autotune® AM transmitter. - view.jpg - -
17L-3 VHF Transmitter, Airborne Airborne VHF (118-135.9 mc), 180 channel, AM, 8 watt transmitter. - - view.pdf -
17L-4 VHF Transmitter, Airborne Airborne VHF (118-135.95 mc), 260 channel, AM, 25 watt transmitter. - - view.pdf -
17L-7 VHF Transmitter, Airborne
p/o FD-104		 Airborne VHF (118-151.95 mc), 680 channel, AM, 25 watt transmitter. - - view.pdf -
17L-8 VHF Transmitter, Airborne
p/o FD-104		 Airborne VHF (118-126.9 mc), 90 channel, AM, 3 watt transmitter. Input power 27.5 vdc. - - view.pdf -
17L-8A VHF Transmitter, Airborne Airborne VHF (118-126.9 mc), 90 channel, AM, 3 watt transmitter. Input power 13.5 or 27.5 vdc. - - 056 0482 00
view.pdf		 -
18A HF Transmitter HF transmitter built special for the Columbia Broadcasting System (CBS) in the late 1930’s. The unit is a 100-watt AM product with three crystal-controlled frequencies. The builders plate say’s this is serial number 5191. However, we have no record of how may CBS actually purchased. Included in the package was an 18A power supply and a portable gasoline engine/generator. - - - view.jpg
18B HF T/R Shipset 18B ship-set, manufactured for the Colombian Air Force in the late 30’s included the 17A transmitter with antenna tuner, 17A receiver, two 28VDC to plate voltage dynamo converters, a junction box, remote control, microphone & headset, and a portable antenna. - - - view.jpg
18C HF T/R Shipset 18C ship-set, manufactured for the Colombian Air Force in the late 30’s included the 16A transmitter/receiver, antenna tuner, two 28VDC to plate voltage dynamo converters, a junction box, remote control, microphone & headset, and a portable antenna. - - - view.jpg
18D HF T/R Shipset 18D ship-set, manufactured for the Colombian Air Force in the late 30’s included the 15A transmitter/receiver, 28VDC to plate voltage dynamo converter, antenna tuner/remote control, microphone & headset, and a portable antenna. - - - view.jpg
18H HF Relay Transmittter 50 watt, AM crystal-controlled Transmitter, 1500 - 3000 kc. For remote to studio relay of broadcast operations. view - - -
18J VHF/UHF Transmitter 10 watt, 56 mc, crystal controlled transmitter for police vehicles. - view.jpg - -
18M Field Set Low power HF transmitter-receiver unit for portable operation - view.jpg - -
18S-4A HF Transmitter/Receiver 20 crystal-controlled frequencies, 2-18.5 mc, 100 watts. Receiver uses IF-stage mechanical filter. - - view.pdf -
18Z HF SSB Comm 28,000 channel, 2-30 Mhz, 1 Khz steps, 1KW PEP - - - -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
20B HF Transmitter 750w - 1kw High Fidelity (freq. response, 1.5 db 30-10,000 c.p.s.) HF (500 kc - 20 mc) AM transmitter. view - - -
20C HF Transmitter 1 kw High Fidelity (freq. response, 1.5 db 30-10,000 c.p.s.) AM transmitter. - view.jpg - -
20E-8A Permeability Tuned Oscillator Permeability Tuned Variable Frequency Oscillator unit. Intended for amateur radio home-built transmitter exciter designs. view - - -
20H Broadcast Transmitter 500/1000 Watt Broadcast (550-1700 kc.) Transmitter. The 20H uses a pair of 833 tubes in the power amplifier. The 20J uses a pair of C-849A tubes in the power amplifier. view - - -
20J HF Transmitter 500/1000 Watt Broadcast (550-1700 kc.) Transmitter. The 20J uses a pair of C-849A tubes in the power amplifier. The 20H uses a pair of 833 tubes in the power amplifier. view - - -
20K HF Transmitter 1 kw, 540-1600 kc Transmitter. view - - view.jpg
20T-1 HF Transmitter 1,100 watt, AM broadcast (540-1600 kc) transmitter. view - - view.jpg
20V-2 1 Kw Am Transmitter Selectable power output of 1,100 or 500 watts AM for the 540-1600 Kc band. Versions up to 15 Mc available. - - view.pdf -
20V-3 HF Transmitter Selectable power output of 1000, 500, or 250 watts AM for the 540-1600 kc band. Versions up to 12 Mc available. - - view.pdf -
21A 5 Kw AM Transmitter Selectable power output of 5,500 or 1,100 watts AM for the 540-1600 Kc band. Versions up to 10 Mc available. - view.jpg - view.jpg
21E 5 kw AM Transmitter Selectable power output of 5,000 or 1,000 watts AM for the 540-1600 kc band. Versions up to 10 Mc available. - - view.pdf -
21M 10 kw AM Transmitter Selectable power output of 10,000 or 5,000 watts AM for the 540-1600 kc band. Versions up to 10 Mc available. - - view.pdf -
237-A Unidirectional Antenna HF Log Periodic construction. 237A-1, A-2, A-3 cover 6.5-60, 11.1-60, 19-60 mc, respectively. view - - -
242F-5CL Ground-To-Air Transmitter Ground-based, Continuous duty VHF-AM voice communications transmitter. view - - -
26C Limiting Amplifier Audio compressor for use in the broadcast industry to limit transmitter modulation to less than 100%. - view.jpg - -
26U-1 Limiting Amplifier Monophonic, audio compressor for use in the broadcast industry to limit transmitter modulation to less than 100%. - - 056 0567 00
view.pdf		 -
26U-2 Limiting Amplifier Stereophonic, audio compressor for use in the broadcast industry to limit transmitter modulation to less than 100%. - - 074 3054 00
view.pdf		 -
30B Modulator
p/o 150W & 150BW		 Provides class B (AM) modulation for the 100B and 150 class transmitters - - view.pdf -
30FX HF Transmitter 100 Watts CW - 40 watts Phone using control grid modulation. 1500 to 15000 kc operation. view view.jpg - -
30FXB HF Transmitter 100 watts phone, using the 203A tubes, from 1500 to 15,000 kc HF band. view view.jpg - -
30FXC HF Transmitter 200 watts phone from 1500 to 15,000 kc band. 10X RF unit available for 1.5-30 mc. view view.jpg - -
30J Multi-band Transmitter 250-200 watt, Am or CW, 1.5-60 mc transmitter. - view.jpg - -
30K-1 HF Transmitter The Type 30K Transmitting system provides coverage of the 80, 40, 20 15, 11 and 10 meter bands at 250 watts phone, 300 watts CW. view - - -
30K-5 HF Transmitter The Type 30K Transmitting system provides coverage of the 80, 40, 20 15, 11 and 10 meter bands. 2-15 mc: 250 watts phone, 300 watts CW; 15-24 mc: 200 watts phone, 250 watts CW; 24-30 mc 150 watts phone, 225 watts CW. - - 056 0270 00
view.pdf		 -
30L-1 HF Linear Amplifier The 30L-1 Linear Amplifier has 1000 watts PEP power input on SSB and 1000 watts average on CW on all amateur bands. - - - view.jpg
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
30S-1 HF Linear Amplifier Requiring 70-100 watts driving power (supplied by the Collins 32S-3 Transmitter or KWM-2 Transceiver) the 30S-1 Linear Amplifier provides SSB and CW station with the full legal power input for SSB (1 kw average) or 1 kw input for CW transmission. - - - view.jpg
30W HF Transmitter 30 watt, crystal controlled, four band (160, 80, 40, & 20 meters) CW transmitter. Will operate on phone by adding a 9B class B modulator. - view.jpg view.pdf -
32G HF Transmitter 20 to 50 watts, A1 or A3 emission. Operating from AC power or DC at 12, 24, 32, or 100 volts. view view.jpg - -
32MS-1 Mobile SSB System 100 watt PEP, four channel, 1.6-15 mc mobile communication system. - - view.pdf view.jpg
32MS-1A Mobile SSB System 100 watt PEP, four channel, 1.6-15 mc mobile communication system. - - view.pdf -
32MS-1B Mobile SSB System 100 watt PEP, four channel, 1.6-15 mc mobile communication system, 50 watts AM. Input power: 115 or 230 vac 50-400 cps, 12 or 28 vdc. - - view.pdf view.jpg
32MS-1C Mobile SSB System 100 watt PEP, four channel, 1.6-15 mc mobile communication system, 50 watts AM. Input power: 115 or 230 vac 50-400 cps, 12 or 28 vdc. - - view.pdf view.jpg
32RA/B
museum		 HF Transmitter 50 watt, 4 channel, 1.5-15 mc AM transmitter for the airline or law enforcement agencies. RA is for AC power - 110 VAC RB is for DC power - 12, 24, 32 or 110 VDC - view.jpg - -
32RS-1 HF SSB Transceiver 100 watts PEP, four preset frequencies, 1.6-15 MHz, USB or LSB.. - - 074-3387 00
view.pdf		 -
32S-3 HF Transmitter The 32S-3 Transmitter covers all the amateur bands between 3.4 Mc and 30 Mc with a power input of 175 watts PEP on SSB or 160 watts on CW. - - - view.jpg
32T
museum		 HF Transmitter Four channel, crystal controlled, HF transmitter. - - - -
32V HF Transmitter 150 watts CW, 120 watts Phone. Look and operational feel companion to the 75A Receiver. - - - -
32V-1 HF Transmitter 150 watts CW, 120 watts Phone. Look and operational feel companion to the 75A Receiver. view - - -
32V-2 HF Transmitter 150 watts CW, 120 watts Phone. Look and operational feel companion to the 75A Receiver. view - - -
35Q-1 UHF Bandpass Filter
p/o 35R-1 & 35S-1		 UHF (755-985 mc) Coaxial Bandpass Filter. - - view.pdf -
35R-1 UHF Branching Filter UHF Coaxial Branching Filter.
High Pass = reject 7 mc band in the 755-885 mc range and pass in the 855-985 range.
Low Pass = reject 7 mc band in the 855-985 mc range and pass in the 755-885 mc range.		 - - view.pdf -
35S-1 UHF Low-pass Filter UHF low-pass filter to reject (-3 db) all frequencies above 1050 mc (-40 db) at 1500 mc. Rated for operation at 10 kw. - - view.pdf -
37J-3 VOR Antenna
p/o 51R or 51X		 Airborne, horizontally-polarized, VOR (108-122 mc) antenna. - - view.pdf -
37M FM Broadcast Antenna Horizontal radiation FM Ring Antenna. 37M-1 to -8 indicate the number of rings in an array. - - 056-0645-00
view.pdf		 -
37R-2U VHF/UHF Antenna Fiberglass airborne VHF/UHF blade antenna. - - view.pdf -
40B HF Transmitter 1,715-14,300 kc (coils available for other bands) CW and AM operation. Add a 5C microphone and a 90C audio input amplifier and you’re good-to-go! - view.jpg view.pdf -
40G RF Unit
p/o 207B-1		 Crystal controlled RF oscillator/exciter. - - - -
45A HF Transmitter First advertised in October 1934, the 45A touted: 40 Watts phone, 125 watts CW; 1,500-30,000kc operation, control grid modulation, built-in power supply, using a complement of twelve tubes. view view.jpg - -
50A HF Receiver HF receiver using two plug-in coil assemblies to change bands. - - - view.jpg
50S Control Console
p/o 18J		 Desktop radio control console targeted for police departments. Contains the 50S Transmitter/Receiver, Speaker, Handset and associated controls. - view.jpg - -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
51F FixedTune Receiver Fixed frequency, AM receiver, operating from 1.5-20 mc. - view.jpg - -
51J-4 HF Receiver The operating range of 540 kc to 30.5 mc is covered by 30 one-megacycle bands. The receiver is designed for amplitude-modulated and continuous wave reception. It uses a PTO & Mechanical Filters. view - - view.jpg
51N-8 HS SSB Receiver Fixed-base rack-mounted HF Single Side Band receiver for operations from 2 - 30 mc. The 51N-8 is available in several models for fixed Side-Band operation (51N-8 AL, AU, DL, DU, BL, BU, E, CL, F, G). view - - -
51R VHF Receiver, Airborne Airborne VHF Receiver. - - - -
51R-2 Navigation Receiver Airborne VHF (108-136 mc.) 280 channel, Navigation Receiver. The 336A-2 omni-bearing selector serves as the control head. view - - -
51S-1 HF Receiver The 51S-1 Receiver operates using USB, LSB, AM, and CW signals in the range of 0.2 to 30.0 MHz. view - - view.jpg
51V-3 Glideslope Receiver
p/o FD-104		 20 crystal-controlled channels. - - - -
51X-2 VHF Receiver, Airborne
p/o FD-104		 Airborne VHF (118-136 mc), 880 channel, AM, receiver. - - - -
51Y-7 ADF Receiver
p/o DF-206 ADF System		 Airborne Automatic Direction Finder (ADF), 190-1750 kHz frequency range. See also 614L-11, -12, and -13 Control Units. - - view.pdf -
51Z-2 Marker Beacon Receiver
p/o FD-104		 Aural and visual indication of passage over 75 Mhz marker beacon stations. - - - -
60CA Speech Mixer Rack-mounted, four-channel audio mixer unit. - - - view.jpg
62S-1 Transverter, 6 & 2 Meters The 62S-1 permits you to enjoy operation on either 6 or 2 meters by simply snapping a switch.
62S-1 is designed for use with the S/Line, KWM-2 and KWM-1; however, it will convert signals from most amateur equipment operating in the 14.0-14.2 mc range.		 - - - view.jpg
70E-8 Permeability Tuned Oscillator The 70E-8 Permeability Tuned Oscillator (PTO) RF exciter unit. Dial covers the 80, 40, 20, 15, 11, 10 meter bands. view - - -
75A HF Receiver 80 meters - 3.2-4.2 mc, 40 meters - 6.8-7.8 mc, 20 meters - 14.0-15.0 mc, 15 meters - 20.8-21.8 mc, 11 meters - 26.0-28.0 mc, 10 meters - 28.0-30.0 mc view - - -
75A-1 HF Receiver 80 meters - 3.2-4.2 mc, 40 meters - 6.8-7.8 mc, 20 meters - 14.0-15.0 mc, 15 meters - 20.8-21.8 mc, 11 meters - 26.0-28.0 mc, 10 meters - 28.0-30.0 mc view - - -
75A-2 HF Receiver 160 meters - 1.5-2.5 mc, 80 meters - 3.2-4.2 mc, 40 meters - 6.8-7.8 mc, 20 meters - 14.0-15.0 mc, 15 meters - 20.8-21.8 mc, 11 meters - 26.0-28.0 mc, 10 meters - 28.0-30.0 mc - - - view.jpg
75A-3 HF Receiver 160 meters - 1.5-2.5 mc, 80 meters - 3.2-4.2 mc, 40 meters - 6.8-7.8 mc, 20 meters - 14.0-15.0 mc, 15 meters - 20.8-21.8 mc, 11 meters - 26.0-28.0 mc, 10 meters - 28.0-30.0 mc view - - -
75A-4 HF Receiver - - - - -
75S-3B HF Receiver The 75S-3B is a versatile receiver with exceptionally sharp selectivity and operation in any of three modes - SSB, CW, and RTTY. AM reception is provided, and the passband can be optimized by the installation of an optional 3.1, 4.0 or 6.0 Kc Mechanical Filter. - - - view.jpg
90C Microphone Amplifier
p/o 40B		 May be used with a carbon or condenser type microphone. - - - -
117H-5 Control Head
p/o 18J		 Under dash mounted Control Head for the 18J Police Radio System. - view.jpg - -
127E Multi-band Transmitter 500 watts A1, 300 watts A2 & A3, 2000-16000 kc operating frequency. - view.jpg - -
137X-1 VHF Antenna, Airborne
p/o 17L-7		 - - - - -
150A HF Transmitter 100 watt, CW only, transmitter for the four (160, 80, 40, and 20 meter) amateur radio bands. - view.jpg view.pdf -
150B
museum		 HF Transmitter 100 watt, CW and AM phone, transmitter for the four (160, 80, 40, and 20 meter) amateur radio bands. - view.jpg view.pdf -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
150C HF Transmitter 100 watt, 1500-15,000 kc, AM Radiophone Transmitter view - - -
152J-1 Phone Patch Unit
p/o 32RS-1		 Matches a 600 ohm telephone line to the 32J-1 transmit and receive audio circuits effectively isolating receiver and transmitter functions. - - view.pdf -
180K-3 Antenna Tuning Unit
p/o 18S-4A		 Airborne transmitter-to-antenna matching unit. Uses a 496B-1 Autotune® unit to synchronize the antenna tuning unit with the transmitter-receiver. - - view.pdf -
180L-2 Antenna Tuning Unit
p/o 18S-4A		 Airborne transmitter-to-antenna matching unit. - - view.pdf -
180V-2 Antenna Coupler
p/o 32RS-1, 32MS-1		 Preset, automatically switched, four channel tuner for coupling the 32RS-1, 32MS-1 line of transceivers to an appropriate antenna. - - view.pdf -
202A HF Transmitter 1 kilowatt operating from 1500 to 30,000 kc. view view.jpg - -
207B-1 HF Broadcast Transmitter 35 kilowatt AM or 50 kilowatt CW, 4-26 MHz, HF transmitter for high speed telegraphic or broadcast transmission. Used by Voice Of America stations. - - - -
212E-1 Speech Input Console Dual channel high fidelity audio program control unit capable of mixing 9 of 22 inputs. - - - -
212F-1 Speech Input Console Single channel high fidelity audio program control unit capable of mixing 5 of 12 inputs. - - - -
231C Multi-band Transmitter 1 kw, 10 frequency, 2,500-20,000 kc, AM, remote-controlled transmitter. - view.jpg - -
231D Multi-band Transmitter 3 kw, 10 frequency, 2,500-15,000 kc or 4,000-20,000 kc, AM & CW, remote-controlled transmitter. - view.jpg - -
300BA HF Transmitter 250 watt AM radiotelephone high fidelity transmitter. view view.jpg - -
300C HF Transmitter Selectable power output of 200 or 100 watts AM for the 540-1600 Kc band. - view.jpg - -
300F HF Transmitter 250 watt, AM, 540-1500 kc, broadcast transmitter. - view.jpg - -
300G HF Transmitter 100/250 Watt AM Broadcast (540-1600 kc.) Transmitter. view - - -
300G-1 HF Transmitter 250 watt, AM, 540-1600 kc, broadcast transmitter. - - - view.jpg
300J-2 250 Watt AM Transmitter Selectable power output of 275 or 110 watts AM for the 540-1600 Kc band. Versions up to 15 Mc available - - - -
310B HF Exciter The 310B RF exciter produces 15 watts covering the 80, 40, 20, 15, 11, 10 meter bands. This product utilizes the 70E-8 Permeability Tuned Oscillator (PTO). - - - -
312B-3 Speaker The 312B-3 contains a 5x7-inch speaker and is styled to match the S/Line and KWM-2. - - - view.jpg
312B-4 Speaker Console The 312B-4 integrates the 75S-3B, 32S-3, 30S-1 and accessories into an operating system. A speaker, RF directional wattmeter with 200 and 2000 watt scales, and a phone patch are included in the console. - - - view.jpg
314S-4 Remote Control Head
p/o 18S-4A		 Remote control unit for use with a 18S-4A airborne transmitter-receiver. - - view.pdf -
314Y-1 Control Panel
p/o 17L-3 Transmitter		 Airborne control panel for the 17L-3 VHF transmitter, allowing frequency selection of the 180 possible channels. - - - -
314Y-2 Control Panel
p/o 17L-4		 Airborne control panel for the 17L-4 VHF transmitter, allowing frequency selection of the 360 possible channels. - - - -
331A Course Line Indicator Panel-mounted instrument for displaying the aircraft position with respect to the chosen course. 1. Omni range or locator course 2. Compass heading & deviation 3. To-from 4. Bearing To or From station circa late 1940s view - - -
331C-4E BDHI Bearing-Distance-Heading Indicator. circa 1950s view - - -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
331C-4F BDHI Bearing-Distance-Heading Indicator. circa 1960s view - - -
374C-1 TACAN
p/o TCN-101 or AN/ARN-21		 Airborne TACAN Transmitter-Receiver Unit. view - - -
415E-1 Power Supply
p/o 18M		 Vibrator type - power inverter and battery. - view.jpg - -
416M Power Supply
p/o 18M		 Dyna-motor type power supply. - view.jpg - -
424B-1 TACAN
p/o TCN-101 or AN/ARN-21		 Airborne TACAN Power Supply and Indicator Coupler unit. view - - -
427A-1 Power Supply, Airborne
p/o 17L-8		 Transistorized modulator & power supply for the 17L-8 VHF airborne transmitter. - - view.pdf -
478R-2 Spectrum Analyzer Base-band Spectrum (3-2,000 kc) Analyzer used in conjunction with a recorder or oscilloscope. view - - -
478V-1 UHF Converter Test Set This test set converts signals generated by exciters or transmitters operating in the 700 to 1,000 mc range to receive signals in the same band but displaced 120 mc. view - - -
500BX Power Supply
p/o 10A		 Provides 500, 300, and -300 vdc; 7.5 and 2.5 vac for the 10A Crystal Control Unit. - - view.pdf -
516F-2 AC Power Supply
p/o 30S-1		 Integral power supply sub-assembly for the 30S-1 linear RF power amplifier. - - - -
550A-1 500 Watt AM Transmitter Selectable power output of 500 or 275 watts AM for the 540-1600 Kc band. Versions up to 15 Mc available. - - - -
600A HF Transmitter 700-800 watts CW, 200 watts Phone. Amateur radio bands. - view.jpg - -
614L-11 Control Unit
p/o DF-206 ADF System		 Single-frequency control head for the DF-206 airborne ADF system. - - view.pdf -
614L-12 Control Unit
p/o DF-206 ADF System		 Dual-frequency control head for the DF-206 airborne ADF system. - - view.pdf -
614U-1 Control Panel
p/o 17L-7		 Airborne single-frequency control head for the 17L-7 VHF Transmitter. - - - -
621A-2 Transponder - - - - -
821A-1 HF Transmitter 250 Kilo-watt AM & FSK HF transmitter (3.95 - 26.5 Ms) with Autotune capability. view - - -
1000A Multi-band Transmitter 3 kw, 10 frequency, 2,500-20,000 kc, AM, remote-controlled transmitter. - view.jpg - -
1200BX HV Power Supply
p/o 150W & 140BW		 Provides 1000-1100 vdc and 10 vac. - - view.pdf -
2500A HV Power Supply
p/o 200B		 Provides 1500 and 1250 vdc; 10 vac. - - view.pdf -
ART-13 HF Transmitter 10-channel Autotune WW-II Airborne HF Transmitter - - - view.jpg
AN/AM-967 UHF Power Amplifier
p/o ARC-27		 Airborne 100 Watt RF Amplifier designed to amplify the output of an RT-178/ARC-27 transmitter. view - - -
AN/APR-13 Radar Receiver Set The APR-13 is a radar receiving (only) set designed to intercept, detect, and display pulsed radar signals. The set is made up of: ID-226/APR-9 (Indicator), TN-178/APR-13 (RF Tuner), CV-124/APR-13 (Mixer Amplifier), C-743/APR-13 (Dzus-mounted Control), and a PP-336/APR-13 (Power Supply). view - - -
AN/ARA-37 UHF Homing Set UHF Homeing Adapter Set may be used with an ARC-27 or ARC-52 Receiver. view - - -
AN/ARC-2/2A HF Transmitter/Receiver Eight Autotune® frequency channels (2-9.05 mc). 15-30 watts AM phone, CW, or mcw. Input power 26.5 vdc. view - view.pdf -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
AN/ARC-38 HF Transeiver Airborne HF (2-25 mc) transceiver A1 and A3 emissions. 100 watts (2.0-14.2495 mc) 90 watts (14.25-25 mc) view - - -
AN/ARC-52 Airborne Comm 1750 crystal-controlled channel UHF (225.0-399.9 mc.) AM Transmitter-Receiver. The C-1607 (Dzus-mounted) control provides 19 presets - including guard. view - - -
AN/ARN-14C Airborne Navigation Receiver Airborne 280 channel, Navigation Receiver, for VOR and LOC. view - - -
AN/ARN-149 ADF Receiver The AN/ARN-149(V) is an Airborne, Low-Frequency (100-2199.5 kHz), Automatic Direction Finder System. - - 523-0774597-20111J
view.pdf		 -
AN/ARR-41 LF/HF Receiver Two band (190-550 kc and 2-25mc) airborne receiver for MCW, CW, and Voice communications. view - - -
AN/ARW-55 UHF Radio Control Set The ARW-55 is a UHF (406-549 mc.) Transmitter, when used in conjunction with a KY-51/ARW (Audio Frequency Coder) and C-615/ARW (Coder Control), provide radio control of remotely guided aircraft. view - - -
AN/ARW-56 UHF Receiver The ARW-65 is a UHF (406-549 mc) FM Radio Receiving Set for remotely-piloted aircraft. view - - -
AN/ARW-59 UHF Receiver
p/o AN/ARW-55		 The ARW-59 is a UHF Receiver when used in conjunction with a KY-55 will allow secured remote control of pilot-less vehicles and missiles. view - - -
AS-505/GR UHF Antenna
p/o AN/GRC-27		 A UHF four-bay, stacked vertical array, wide-band dipole antenna. view - - -
AT-197/GR UHF Antenna
p/o AN/GRC-27		 Omni-directional discone antenna for UHF. view - - -
AT-335 UHF Antenna
p/o AN/ARW-55		 Airborne UHF Antenna. view - - -
C-11927/ARN-149 Control Panel
p/o ARN-149(V)		 Dzus-mounted, Manual Control Head. - - 532-0774597-20111J
view.pdf		 -
C-245A/ARC-2 Control Panel
p/o ARC-2/2A		 Control Panel for the ARC-2 Transmitter-Receiver. - - view.pdf -
C-732/ARC-2 Control Panel
p/o ARC-2/2A		 Radio Set Control for the ARC-2/2A Transmitter-Receiver System. - - view.pdf -
DF-201 ADF System
p/o FD-104		 Provide automatic or manual DF AM, CW reception. 90 to 1800 Khz. - - - -
AN/FRR-33 HF Receiver Dual Diversity HF (0.5-32 mc) Receiver using two R-391 (ten-channel Autotune) Receivers. For FSK teletype service. view - - -
AN/FRR-34 HF Receiver Triple Diversity HF (0.5-32 mc) Receiver using three R-390 Receivers. view - - -
AN/FRT-22 HF Transmitter Ten-channel, Autotune, 40 kilowatt transmitter designed for 4.0-26.5 megacycles. view - - -
AN/FRT-26 HF Transmitter Ten-channel, Autotune, 15 kilowatt radiotelegraph (FSK) transmitter designed for 4-26 megacycle operation. view - - -
AN/FRW-2 UHF Transmiiter 500 watt UHF FM Transmitter (406-539 mc) for guiding pilot-less vehicles. view - - -
AN/FRW-2 UHF FM Transmitter 144 channel (406-559 mc), UHF FM Transmitter (20 fixed frequency audio tones) for use at missile test sites. view - - -
AN/FRW-3 UHF FM Receiver 144 channel (406-559 mc), UHF FM Receiver (20 fixed frequency audio tones) for use at missile test sites. view - - -
GRC-19 HF Transmitter The T-195/GRC-19 is a ground or vehicle Voice, CW, or FSK - HF (1.5-20 mc) Transmitter. It is a companion to the R-393/URR Receiver. view - - -
AN/GRC-27 UHF Comm Ground based UHF (225.0-399.9 mc.) rack-mounted Transmitter/Receiver & Antenna system. view - - -
ID-416 Distance & Radio Mag Indicator Panel-mounted combination Distance and Radio-magnetic Indicator. view - - -
Type No. Function
part of another		 Brief
Description		 Brochure Ad Copy Product
Sheet		 Photo
KW-1 HF Transmitter Covers Amateur Bands: 160, 80, 40, 20, 15, 11, and 10 meters providing 1000 watts RF input power (500 watts on 160 meters). - - - -
KWM-1 HF Transceiver The KWM-1 covers the frequency range of 14-30 mc with an input of 175 watts PEP or SSB. - - - view.jpg
KWM-2 HF Transceiver The KWM-2 power input is 175 watts PEP on SSB or 160 watts on CW. It transmits on voice or CW with a nominal output of 100 watts for complete coverage on 80 through 10 meters. Crystals are provided for all HF bands except 10 meters where one crystal is supplied with provision for two additional crystals. - - - view.jpg
KWS-1
museum		 HF Transmitter Self-contained Exciter and Power Amplifier, provides 1 kW peak envelope power on SSB, 1 kW CW operation for the 80-10 meter amateur bands. - - - -
KY-171/URW Telemetry Encryption
p/o AN/FRW-2		 While the KY-171 does not perform voice encryption, it does perform audio frequency encryption of telemetry data in combination with the decoder and coder control devices. Functioned using 20 audio channels. - - - -
MD-129A Power Supply
p/o AN/GRC-27 and OA-104		 Power Supply and Modulator for the T-217A UHF Transmitter. view - - -
OA-252/GR HF Comm RF Amplifier 5000 Watt HF (1.5-30 mc) RF Amplifier providing CW, FSK, FAX, SSB, or AM transmissions. view - - -
R-278B/GR UHF Receiver
p/o AN/GRC-27		 1750 channel, UHF (225.0-399.9 mc.) AM Receiver used for communications and direction finding. view - - -
R-389/URR LF Receiver General purpose LF Receiver (5 bands at 15-500 kc) and (2 bands at 500-1500 kc) Voice, CW, or FSK. view - - -
R-390A/URR
museum		 HF Receiver HF (500 kHz - 31.999 mHz), AM or CW, receiver.
Used by the military during WW II, Korean war, Vietnam war, Desert Storm, and the war in Iraq.		 view - - -
R-392/URR HF Receiver The R-393/URR is a ground or vehicle Voice, CW, or FSK - HF (1.5-20 mc) Receiver. It is a companion to the T-195/GRC-19 Transmitter. view - - -
TCN-101 TACAN The TCN-101 is system made up of: 374C-1 (Receiver-Transmitter), 424B-1 (Power Supply Coupler), 614S-1 (Dzus-mounted Control), 331A-2 (Course Indicator), and 331C-4 (Distance & Radio Magnetic Indicator). view - - -
TCS-12, RX
museum		 HF Receiver Produced for the U.S. Navy Department during WW II
HF CW and Voice on three bands; 1.5-3, 3-6, and 6-12 MC.
The TCS-12 Receiver required a separate Power Supply providing 12 and 220 VDC - the latter from a motor-generator system.		 - - - -
TCS-12, TX
museum		 HF Transmitter Produced for the U.S. Navy Department during WW II
HF CW and Voice on three bands; 1.5-3, 3-6, and 6-12 MC.
The TCS-12 Transmitter required a separate Power Supply providing 12, 220, and 400 VDC - the latter two from a motor-generator system.		 - - - -
AN/TRC-32 Transportable UHF Comm Set 1750 channel UHF (225.0 - 399.9 mc) ground-to-air communications set. view - - -
T-216/GR UHF Signal Generator 1750 channel UHF (225-399.9 mc) AM Signal Generator for testing Radio Direction Finding installations. view - - -
T-217A/GR UHF Transmiiter
p/o AN/GRC-27 & OA-104		 1750 channel, UHF (225.0-399.9 mc.) AM Transmitter used for communications and direction finding. view - - -
T-276/UR HF Communications Transmitter 500 watt, twin sideband, HF (1.7-30 mc) Communications Transmitter intended for multiplex service. view - - -
AN/URC-8 HF Communications HF Comm (2.0 to 30 mc) AM/CW Transmitter and Receiver set. Powered by a PP-1190/URC-8 (115-230 VAC 50, 60, or 400 cps) or a DC to DC dynamotor (12, 28, 115, or 230 VDC) view - - -
AN/URC-9 UHF Comm Ruggedized 20 watt UHF Vehicular communications set. Operates in the 225.0 to 399.9 mc range. view - - -
AN/VRC-24 UHF Transmiiter/Receiver 1760 channel UHF AM (225.0 - 399.9 mc) transmitter/receiver set. view - - -

Friends of the Collins Aerospace Museum is solely responsible for the content of this web site. Such content does not necessarily reflect the views of Collins Aerospace.
Copyright ©2024 Friends of the Collins Aerospace Museum • All rights reserved.
